AIMS Power LFPGLFCHG 48V 20A Charger for Golf Cart Batteries

Description

Input Voltage 96-145VAC full performance
70-96VAC automatically de-rate to 50% of full load current
Frequency 40Hz to 70Hz
Nominal Input Current at Rated Output <9Aac Voltage Measurement Accuracy ±8Vac Frequency Measurement Accuracy ±1Hz Output Nominal Voltage 36/48Vdc manual adjustable Current Input voltage 96-145V, Output current 25A for 36V mode Output current 18.5A for 48V mode Input voltage 70-96V, output current 12.5A for 36V mode output current 9.375A for 48V mode Rated Output Current Manual adjustable Current Accuracy ± 6% of full rated output current @25°C, for target currents across the range from 10% rated output (for absorption exit criteria accuracy) to the current limit setpoint. Load Regulation 1.5% Selectable Battery Type Open Lead-Acid, Gel, AGM, LiFePO4, adjustable Parallel Outputs Maximum of two AC converter units connected in parallel Efficiency 80% Protection Input Over Voltage Unit is safe for input voltage up to 150VacRMS (and up to 215Vpeak). Above this level the damage may occur. Input Under-voltage No permanent damage for input voltages from 0-300Vac. Shutdown or input current limit or other means may be applied when input voltage is out of normal operating range. Output over voltage 12/24V mode 36Vdc. Unit will shut down if Vcharging > Vcharging (target) + 1.0Vdc for more than 2 seconds; unit will restart when voltage <= Vcharging (target) for more than 2 seconds. For battery OVP the unit will restart in the same stage. 48Vdc. Unit will shut down if Vcharging > Vcharging (target) + 1.5Vdc for more than 2 seconds; unit will restart when voltage <= Vcharging (target) for more than 2 seconds. For battery OVP the unit will restart in the same stage. Charger over temperature protection The internal temperatures of the charger will be measured by NTC. Based on these measurements, unit will shut down if the temperature exceeds 105°C. Unit will restart when environment temperature cools to 95 °C. BTS(Battery Temperature Sensing) The battery temperature sensor allows the charge controller to continuously adjust charge voltage / charge current based on actual battery temperature. When the battery temperature is over 40 °C, unit will reduce the charging voltage to Float voltage, also it will reduce the Max charging current by 10% with every two degree of temperature rise. When the battery temperature is over 50 °C, unit will shut down. Environmental Operation temperature Nominal ambient temperature: 25°C Operating Ambient Temperature range: -10°C to 40°C (On the heat sink of DC-DC part, if the temperature is over 90 ℃, the Charger Current will be de-rate to 50% ; if the temperature is over 105 ℃, the Unit will be shut down.) Relative humidity 5～95% without condensation Noise Unit requirements: below 50dB (A) measured at 1 m distance with fan full working. Storage Conditions Temperature -20°C to +80°C Cooling Fan – thermal and load based Mechanical Dimension (D x W x H) 10.25” * 6.75” * 3.25” Unit Weight 6.5 lb Boxed Weight 7 lb
