Description
| Series | 4000 | Warranty | 3 Years |
|---|---|---|---|
| Volts | 12 | BCI | G27 |
| Cells | 6 | ||
| Terminal Type | DT | ||
| Included Hardware | S/S Hex Cap Screw, Nut, Lock & Flat Washer | ||
| Size & Thread | 5/16″-18 | ||
| Charge | |
|---|---|
| Charge Voltage Range | 2.45-2.5 V/cell @ 25°C (77°F) |
| Float Voltage Range | 2.25 V/cell @ 25°C (77°F) |
| Recommended Charge Current | 15 A |
| Maximum Charge Current | 25 A |
| Self-Discharge Rate | 5%-10% per month at 25°C (77°F) |
| Capacity | |
|---|---|
| Cold Crank Amps (CCA) 0°F / -18°C | 660 |
| Marine Crank Amps (MCA) 32°F / 0°C | 825 |
| Reserve Capacity (RC @ 25A) | 185 Minutes |
| Reserve Capacity (RC @ 75A) | 53 Minutes |
| Hour Rate | Capacity / AMP Hour | Current / AMPs |
|---|---|---|
| @ 100 Hour Rate | 140 AH | 1.4 A |
| @ 20 Hour Rate | 105 AH | 5.25 A |
| @ 15 Hour Rate | 99 AH | 6.58 A |
| @ 10 Hour Rate | 89 AH | 8.93 A |
| @ 8 Hour Rate | 87 AH | 10.89 A |
| @ 5 Hour Rate | 85 AH | 17.01 A |
| @ 1 Hour Rate | 38 AH | 37.8 A |
| Ampere hour capacity ratings based on specific gravity of 1.280 at 27°C (80°F). Reduce capacities 5% for specific gravity of 1.265 and 10% for 1.250. |
||
| Specifications | |||
|---|---|---|---|
 |
Weight | 24.5 kg | 54 lbs |
| Length | 32.1 cm | 12.63“ | |
| Width | 17.1 cm | 6.75“ | |
| Height Inc. Term. | 23.8 cm | 9.38“ | |
| Product measurements & weights are calculated based on sample data. Individual specifications are subject to vary due to the manufacturing process & battery components. | |||
| Container | ABS | ||
|---|---|---|---|
| Cover | ABS | ||
| Handles | Plastic Strap | ||
Voltage vs. Depth of Discharge
