Description
MECHANICAL SPECIFICATIONS
| Industry Reference | BCI: 903-L16 | |
| Length A (in/mm) | 11.6 | 295 |
| Width B (in/mm) | 7.1 | 180 |
| Height C (in/mm) | 15.1 | 383 |
| Total Height D (in/mm) | 15.9 | 403 |
| Weight (lbs/kgs) | 116.6 | 53 |
| Terminal * | AM | |
| Technology | DRY CELL AGM, VRLA | |
NOTE 1: Dimensions have a ±2 mm (0.08 in) tolerance. Weights may vary.
NOTE 2: Refer to terminal guide on website for torque values.
ELECTRICAL SPECIFICATIONS
| Voltage (V) | 6 | |
| Internal Resistance (mΩ) | 1 | |
| Short Circuit (A) (20°C / 68°F) | 4900 | |
| Self-Discharge (20°C / 68°F) | 2-3% per month | |
| Charge Temperature | Min: -10°C (14°F) | Max: 50°C (122°F) | |
| Discharge Temperature | Min: -40°C (-40°F) | Max: 50°C (122°F) | |
| Storage Temperature | Min: -20°C (-4°F) | Max: 60°C (140°F) | |
NOTE 3: Extra considerations must be given when designing systems for use at maximum temperatures.
NOTE 4: Internal Resistance is approximate.
PERFORMANCE SPECIFICATIONS
| Amp Hours (AH) | ||
|---|---|---|
| 3 HR | 5 HR | 20 HR |
| 295 | 340 | 390 |
3 HR: 1.70VPC; 5 HR: 1.75VPC; 20 HR: 1.80VPC. All at 25°C/77°F
| Minutes of Discharge | ||||
|---|---|---|---|---|
| @25A | @56A | @75A | @85A | @100A |
| 915 | 375 | 265 | 235 | 190 |
