Description
| Series | FLA SERIES 5000 | Warranty | See Warranty Terms |
|---|---|---|---|
| Volts | 6 | Design | SPEC |
| Cells | 3 | Plates/Cell | 17 |
| Terminal Type | Flag | ||
| Included Hardware | S/S Hex Cap Screw, Nut, Lock & Flat Washer | ||
| Size & Thread | 5/16″-18 | ||
| Charge | Discharge | |
|---|---|
| Charge Voltage Range | 2.45-2.5 V/cell @ 25°C (77°F) |
| Float Voltage Range | 2.25 V/cell @ 25°C (77°F) |
| Self-Discharge Rate | 5%-10% per month at 25°C (77°F) |
| Capacity | |
|---|---|
| Cold Crank Amps (CCA) 0°F / -18°C | 1393 |
| Marine Crank Amps (MCA) 32°F / 0°C | 1742 |
| Reserve Capacity (RC @ 25A) | 1363 Minutes |
| Reserve Capacity (RC @ 75A) | 454 Minutes |
| Capacity Affect by Temperature | 40°C (104°F) |
25°C (77°F) |
0°C (32°F) |
-15°C (5°F) |
|---|---|---|---|---|
| 105% | 100% | 75% | 50% |
| Hour Rate | Capacity / AMP Hour | Current / AMPs |
|---|---|---|
| @ 100 Hour Rate | 733 AH | 7.33 A |
| @ 72 Hour Rate | 693 AH | 9.62 A |
| @ 50 Hour Rate | 656 AH | 13.12 A |
| @ 20 Hour Rate | 568 AH | 28.39 A |
| @ 15 Hour Rate | 528 AH | 35.21 A |
| @ 10 Hour Rate | 505 AH | 50.54 A |
| @ 8 Hour Rate | 488 AH | 61.04 A |
| @ 5 Hour Rate | 454 AH | 90.85 A |
| @ 1 Hour Rate | 256 AH | 255.53 A |
| Specifications | |||
|---|---|---|---|
| Weight | 100 kg | 220.5 lbs | |
| Length | 559 mm | 22“ | |
| Width | 210 mm | 8.25“ | |
| Height Incl. Term. | 464 mm | 18.25“ | |
| Product measurements & weights are calculated based on sample data. Individual specifications are subject to vary due to the manufacturing process & battery components. | |||
| Electrolyte Reserve | 95 mm | 3.75“ | |
|---|---|---|---|
| Container (Inner) | Polypropylene | ||
| Cover (Inner) | Polypropylene – heat sealed to inner container | ||
| Container (Outer) | High Density Polyethylene | ||
| Cover (Outer) | High Density Polyethylene snap fit to outer container | ||
| Handles | Molded | ||
|
|||
Cycle Life vs. Depth of Discharge
Voltage vs. Depth of Discharge
Detailed Illustration
