SKU: SK-6
Original price was: $178.97.$107.38Current price is: $107.38.
| Weight | 2 lbs |
|---|---|
| Dimensions | 5 × 3 × 1.5 in |
| Part No | SK-6 |
| Brand | Morningstar |
| Controller Type | PWM (Pulse Width Modulation) |
| Supported Battery Chemistry | AGM, Flooded (Wet Cell), Gel, Sealed Lead Acid (General) |
| System Voltage Compatibility | 12V |
| Solar Input Voltage | Below 50V |
| Maximum Charging Current | 5A and below |
| Maximum PV Array Wattage | Up to 100W |
| Application | Industrial Systems, Security & Remote Monitoring Stations, Telecommunications |
| Charging Technology & Features | Multi-Stage Charging, Overcharge / Overload / Short Circuit Protection, Reverse Polarity Protection, Temperature Compensation |
| Display & Interface | LED Indicator |
| Build & Protection Rating | IP40 |
| I/O Connection Styles | Hard-Wire Only |
| Portability | Fixed/Wall Mount, Panel/Vehicle Mount |
| Warranty | 3 years |
The SunKeeper-6 is rated for 6 amps solar input at 12 volts and features a weatherproof high temperature enclosure which is rated for hazardous locations. Its LED indicator will monitor the 3 stage charging and indicate system faults. The unit has built in temperature compensation or can use an optional remote temperature sensor (RTS). Comes pre-rewired with fork connectors for a quick and easy installation in a solar module junction box.
| SKU | SK-6 |
|---|---|
| Brand | Morningstar |
| Manual | Data Sheet |
