Description
Specification Details
| Parts per Unit | 100, 500 |
|---|---|
| Features | 600V, UL and CSA certified for indoor or outdoor use, Arctic-grade neoprene, flame-retardant jacket, resistant to oil abrasion, sunlight, acids and alkaline, Fine-stranded copper conductor for maximum conductivity and flexibility, Flexible insulation for easy routing and long, reliable life, Jute or nylon filter with mylar binder to reduce friction, Small-diameter neoprene flexible TC type cable |
| Application | For aerial and work platforms, forklift trucks, maintenance equipment |
| Gauge | 18 |
| Conductor Material | Copper |
| Cable Nominal Outer Diameter | |
| Insulation Material | Neoprene |
| Insulation Thickness | 0.02 in |
| Number of Conductors | 8 |
| Pack Type | Roll |
| Prop 65 Item | DEHP, DINP |
| SAE | No |
| Strand Count | 16 |
| Strand Gauge | 30 |
| Subject to Prop 65 | Yes |
| Temperature Range (°C) | -40 to 90°C |
| Temperature Range (°F) | -40 to 194°F |
| UL / CSA | No |
| Voltage | 600 V |
| Works With | Maintenance Equipment |
| Brand | Not branded |
| Cable Nominal Outer Diameter | 0.42 in |
| Color | 2-Blue, 2-Red, Black, Brown, Green, Orange |
| Product Length | 14.00 in |
| Product Width | 6.00 in |
| Product Type | TC Cable |
| RoHS Compliant | Yes |
| SKU | 220106, 220106-100, 220106-500 |
| Cable Length | 100 ft, 500 ft |
| Product Weight | 14.29 lb, 71.95 lb |
| Country of Origin | USA |
